INOX BOLLARD WITH VERTICAL LEDS

Measures:
Diameter: ø 90 / 104 / 204 mm.
Height: 1000 mm.
Thickness: 2 mm.

Inox light bollard with energy-saving leds, manufactured with a stainless steel tube AISI 304, 2 mm. of thickness, Ø 90 / 104 / 204 and 1000 mm. height.

Led of 500 mm height situated vertically on the bollard body. Possibility of 1,2,3,4 led light strips (one for each bollard front).

Possibility of choosing among different led colors for each bollard front, as well as different models and operating sequencies.

Bollard which provides a great lighting in the urban road, with a lower electrical cost.

Bollard ideal to light up urban roads, pedestrian areas, gardens, entrances, parks...

Standard finishes:

• Glossy finish ø 90 mm. with white leds. - Ref. PINOX90BLVB
• Matt finish ø 90 mm. with white leds. - Ref. PINOX90MLVB
• Glossy finish ø 90 mm. with red leds. - Ref. PINOX90BLVB
• Matt finish ø 90 mm. with red leds. - Ref. PINOX90MLVR


• Glossy finish ø 104 mm. with white leds. - Ref. PINOX104BLVB
• Matt finish ø 104 mm. with white leds. - Ref. PINOX104MLVB
• Glossy finish ø 104 mm. with red leds. - Ref. PINOX104BLVB
• Matt finish ø 104 mm. with red leds. - Ref. PINOX104MLVR


• Glossy finish ø 204 mm. with white leds. - Ref. PINOX204BLVB
• Matt finish ø 204 mm. with white leds. - Ref. PINOX204MLVB
• Glossy finish ø 204 mm. with red leds. - Ref. PINOX204BLVB
• Matt finish ø 204 mm. with red leds. - Ref. PINOX204MLVR

Optional:

• Possibility in manufacturing in stainless steel AISI 316.
• Customized logo.
• Other led colors available (blue, green, amber,...).
• Other colors and finishes available.
• Possibility of manufacturing in other measures and diameters.
• Possibility of choosing different LED colors as well. such as patterns and sequences of operation.


Recommended screws:

• For concrete: Taco of 11 - Ref. T11L

• For asphalt / panot: Taco of 10. - Ref. T10X135


Accessories:

• 1 ring for stainless steel bollard. - Ref.S1API
• 2 rings for stainless steel bollard. - Ref.S2API
• Galvanized chain ø 7,5 mm. - Ref. CD08012260
• Galvanized chain ø 6 mm. - Ref. CG6100
• 40mm brass padlock. with steel bow - Ref. CNMCAD40

More information:

Inox led light bollard datasheet
